Naim ND5XS2 Network Streamer



Pin It
  • AUTOMATED ORDERING UNAVAILABLE
    CALL TOLL FREE 855.991.8181 FOR PURCHASE ASSISTANCE
    GREAT MUSIC STREAMER

    The ND5 XS 2 uses our innovative new streaming platform with an expanded feature set. High-res UPnP™ streaming, AirPlay, Chromecast built-in, Bluetooth (apt X HD), Spotify Connect, TIDAL, Roon compatibility, internet radio and multiroom streaming – alongside digital and USB inputs for conventional connections – make this versatile player the ideal partner for one of our integrated amplifiers.

    Carefully selected and matched parts, an oversized toroidal transformer, decoupled PCB boards: the ND5 XS 2 benefits from classic Naim engineering and fastidious attention to detail to ensure that it delivers natural, engaging sound quality from all sources..

    TECHNOLOGY & CRAFT

    The streaming section of the ND5 XS 2 uses the latest Naim network card featuring low-noise, high-speed low-voltage differential signalling (LVDS) to route the digital audio signal. The higher speed is capable of decoding all HD audio formats at up to 32 bits/384 kHz or DSD128. Rather than the source acting as the digital timing master, our new streaming board turns things around and allows our DAC clock to control the flow of audio data. The data is integer-over-sampled in a SHARC DSP to an incredible 40-bit accuracy before it’s fed to the PCM1791A Burr-Brown digital-to analogue converter. .

    Developing a new streaming platform was one of the biggest projects we have ever taken on. Naim engineers across all disciplines – electronic, industrial, acoustic and mechanical – worked for three years to create a system that could make the most of online services such as TIDAL and Spotify while adding future-proof flexibility through Chromecast built-in. Supporting faster data rates with dual-band Wi-Fi and the latest 802.11ac protocol, this robust platform was designed for the highest performance on every level. .

    The NDX 2 features an integrated low-noise power supply with a custom-designed toroidal transformer and separate windings for the digital and analogue sections. However, the player can be upgraded with an external XPS DR or 555 PS DR power supply, giving you a marked increase in sonic authority and emotion.

    During the development of the NDX 2, our engineers examined every detail, from mechanical construction, component selection and board layout. The result is a network player worthy of the Naim badge, with a sound that’s rich, detailed and engaging.

  • FEATURES
    • UPnP-enabled to allow streaming of audio files at up to 32bit/384kHz resolution from Naim Audio hard disk servers, network-attached storage (NAS) devices or any home computer
    • Supports a broad range of music formats: WAV, FLAC, DSD, Apple Lossless, AIFF, AAC, Windows Media-formatted files, M4A and MP3. Gapless playback on all file formats
    • Two 24bit/192kHz capable digital inputs (S/PDIF) and two optical inputs to support optimum connection to external sources
    • Built-in Chromecast allows you to stream from hundreds of supported smartphone or tablet apps (192kHz)
    • Apple AirPlay - stream music from your iOS device or from iTunes and Apple Music
    • Spotify Connect built-in to stream millions of songs from the world’s most popular streaming service
    • Native support for TIDAL streaming service with free 90 day trial of lossless HiFi tier
    • Front-panel USB port for replay of MP3 player and USB-stored audio (1.6A charge)
    • vTuner 5* full-service internet radio
    • Multiroom & Party Mode compatible
    • iOS and Android Naim Audio app for intuitive control
    • Bluetooth connectivity with aptX codec for quality audio playback
    • Thanks to RC5 system integration, you can control compatible amplifiers that are connected to your network player directly from the Naim app on a phone or tablet
    • Roon ready - turning your music collection into a beautifully laid out catalogue
  • SPECIFICATIONS:
    Audio Inputs
    Digital (S/PDIF)

    2 x optical TOSLink (up to 24bit/96kHz)
    1 x coaxial RCA (up to 24bit/192kHz, DoP 64Fs)
    1 x coaxial BNC (up to 24bit/192kHz, DoP 64Fs)

    USB

    2 x USB Type A socket (front and rear - 1.6A charge)

    Streaming

    Chromecast built-in, Apple AirPlay, TIDAL, Spotify® Connect, Bluetooth (AptX HD), Internet Radio, UPnP™ (hi-res streaming), Roon Ready

    Audio Outputs
    Analogue

    1 x RCA pair
    1 x 5-pin DIN

    Connectivity
    Network

    Ethernet (10/100Mbps), WiFi (802.11 b/g/n/ac with external antennae)

    Multiroom

    Party Mode Streaming: Sync up to six Naim products and control via the Naim app

    Updates

    Update your system wirelessly via the Naim app

    Ripping and Storage
    Storage

    2 x USB Type A socket (front and rear - 1.6A charge)

    Formats
    Audio Formats

    WAV - up to 32bits/384kHz
    FLAC and AIFF - up to 24bit/384kHz
    ALAC (Apple Lossless) - up to 24bit/384kHz
    MP3 - up to 48kHz, 320kbit (16 bit)
    AAC - up to 48kHz, 320kbit (16 bit)
    OGG and WMA - up to 48kHz (16 bit)
    DSD - 64 and 128Fs
    M4A - up to 48kHz, 320kbit (16 bit)
    Note: Gapless playback supported on all formats.

    Internet Radio Formats

    Windows Media-formatted content, MP3, ACC, OGG Vorbis streams and MMS

    Internet Radio Provider

    vTuner premium 5*

    Power
    Power Consumption

    Typical use: 11W
    Network standby mode: <2W
    Deep sleep: <0.5W

    Mains Supply

    100V, 115V or 230V; 50 or 60Hz

    User Control
    App Control

    Naim App for iOS and Android

    Physical
    Weight

    6.6kg

    Finishes

    Brushed and anodised aluminium

    Supplied with

    Power-Line Lite cable (UK denominations only), 5-pin DIN interconnect cable, BNC to RCA adaptor, Wi-Fi (x2) and Bluetooth antennae, cleaning cloth, quick start guide

    Upgrades
    Mains Cable

    Power-Line
