Bel Canto Design DAC 2.8 DAC

Pin It
  • DACControlPreamplifier, HDR Core, 24-bit 192kHz dual deferential DAC with24-Bit Volume Control Balanced I/O, 5DigitalInputs, Analog Input,  USB2.0, 1/4-inch Front Panel Headphone Output with 300mA HighCurent Low Impedence dedicated amplifier, Remote. White display.

  • Incredible audio performance, features and flexibility, the DAC2.8 is musically open, detailed and natural sounding. HDR Core is the result of 25+ years of engineering to refine the digital to analog process and is comprised of 3 major components: Low Noise and Ultra Low Noise Master Clocks, Advanced Asynchronous Interfaces and Dual Mode Low-Noise High Efficiency Power Supplies. HDR Core technology is fundamental to every e.One DAC and Integrated product, creating the most realistic, open and defined musical experience possible.

    Built In Headphone Output

    This low-impedance, high-output headphone amp circuit has been designed to drive any pair of high quality headphones with pristine clarity. You'll be amazed at the musical depth they bring to your headset.

    Simple, Elegant Interface

    Designed to be functional and simple, the dual-functioning one knob interface is a joy to use. The programmable 8 character display works with it seamlessly to access all basic functions in a few clicks. The included 36 button infrared remote allows instant command functions and display editing.

    Asynchronous USB Input

    24/192 Asynchronous input works with the internal dual Ultra Low Noise Femtosecond clocks to provide unprecedented audio sound quality and impact from your computer audio sources.

    • Class Leading 124dB Dynamic Range
    • 24 Bit Volume Control
    • 24/192 Asynchronous USB 2.0
    • Analog Input
    • 5 Asynchronous Digital Inputs
    • High Current Headphone Output Driver
    • Remote Control
    • Available in Black or Silver Faceplate
    • MAC USB 2.0 compatibility and custom Windows USB 2.0 driver

    Maximum Data Input Rate:
    24bit Data at 192KS/s:  AES XLR, SPDIF BNC/RCA, TOSLINK, USB
    Master Clock jitter:  70 femtoseconds RMS, 100Hz-1MHz


    Maximum Output:  4.4Vrms balanced XLR, 2.2Vrms RCA
    Output Impedance:  200 ohms balanced XLR, 100 ohms RCA
    Frequency Response: 20 Hz-20 KHz, +/- 0.5dB
    THD+N:  <0.0015%, 4Vrms balanced out, 1KHz
    Output Noise:  3.3uVrms A-weighted 20Hz-20KHz
    Dynamic Range:  124dB A-weighted 20Hz-20KHz


    Maximum Input:  2.5 Vrms RCA
    Input Impedance:  12K ohms RCA
    THD+N:  0.003%, 2.5Vrms in, 1KHz
    Dynamic Range:  110dB, A-weighted 20Hz-20KHz


    Headphone Output Current and Voltage Level: 300mA peak at 4Vrms
    Maximum Output:  138mW
    THD+N:  0.01% 35mW, 1KHz
    Output Noise:  17uVrms, A-weighted 20Hz-20KHz


    Power Usage On:  7W
    Power Usage Off:  0.0W
    Power Requirement:  100-120VAC, 220-240VAC 50/60 Hz
    Dimensions:  8.5" W x 12.5" D x 3.5" H (216 mm x 318 mm x 88 mm)
    Weight:  14lbs. (6.5 kg)
