Lumin X2 Network Music Streamer Player with DAC

$ 16,800.00

Pin It

Latest processing system

The first LUMIN flagship to feature our fastest processor
First launched in 2022, the latest architecture provides a new foundation for LUMIN
Increased processing power and storage capacity provide greater resampling flexibility, audio processing performance and future-proofing.
Up/down sampling up to DSD256

External dual-toroidal linear power supply

- Solid billet construction using all the same techniques as the main chassis
- Thick aluminium walls provide even more shielding
- Separate digital and analogue circuitry
- Low-noise Linear Regulator
- The highest quality components used throughout

X2 SPECIFICATION

DSD SUPPORT:
- Up to DSD512 22.6MHz, 1-bit
PCM SUPPORT:
- Up to 768kHz, 16–32-bit, Stereo
ANALOG OUTPUT STAGE:
- LUMIN Discrete DAC
- Fully balanced layout with high-quality components
- Output connectors coupled with dual LUNDAHL LL7401 output transformers
- Femto Clock System with precision FPGA distribution
UPSAMPLING RATES & BIT DEPTHS:
- DSD256 upsampling option for all files
- PCM 384kHz upsampling option for all files
DIGITAL OUTPUT STAGE:
- USB:
  - Native DSD512 support
  - PCM 44.1–768kHz, 16–32-bit, Stereo
- BNC SPDIF:
  - PCM 44.1kHz–192kHz, 16–24-bit
  - DSD (DoP, DSD over PCM) 2.8MHz, 1-bit
OPTICAL NETWORK:
- Industry-standard Gigabit SFP
- 1000Base-T Gigabit Ethernet
- Adapter may be needed for your particular switch/cables
- Use simultaneously with RJ45 (e.g. connect one to router and one to LUMIN L1 or NAS)
POWER SUPPLY:
- External solid billet cnc dual-toroidal
- Separate digital & analogue circuitry
- Low-noise linear regulator
- 9-pin Output Connector
PHYSICAL:
- FINISH:
  - Black anodised aluminium (with matching PSU)
  - Raw anodised aluminium (with matching PSU)
  FEET
  - IsoAcoustics isolating feet on main chassis
  LUMIN (SOLID ALUMINIUM CHASSIS):
  - 350mm (W), 345mm (D), 77mm (H), 8kg
- PSU (SOLID ALUMINIUM CHASSIS):
  - 106mm (W), 334mm (D), 77mm (H), 4kg
