Soundsmith Irox Ultimate Phono Cartridge



Pin It

Next → ← Previous

  • SPECIAL ORDER

    Our ultra-high performance "Unbreakable" cartridge - for those who demand excellent analog reproduction but desire a cartridge that will withstand rough handling without failure. Excellent for Libraries, Schools, Instititutional use, those with unsteady hand control, or turntables that will be used by children. Soundsmith advanced engineering brings you yet another first - uncompromising performance from a nearly indestructible cartridge.

  • SPECIFICATIONS:
    • Cartridge Type: Special Order
    • Output: High
    • Output Voltage: >2.12mV
    • Available As Dual Coil Mono: Yes


    Type: • Fixed Coil / Moving Iron
    Mount: • Standard ½”
    Stylus: • Elliptical Nude, 0.12 mm square
    Radius of Curvature: • 6 x 17 µm
    Cantilever: • Aluminum Alloy
    Recommended Tracking Force: • 2.0 - 2.5 g
    Effective Tip Mass: • 0.55 mg
    Compliance: • 10 µm/mN
    Frequence Response: • 20 - 20,000 Hz ± 2.5 dB
    Channel Separation @ 1000 Hz: • > 26 dB
    Channel Separation @ 50 - 15,000 Hz: • > 20 dB
    Channel Difference: • < 1.6 dB
    Output Voltage @ 5cm/sec: • > 2.12 mV (HIGH)
    DC Resistance (DCR): • 680Ω
    Coil Inductance per channel: • 190 mH
    Suggested Preamp Gain: • 38 - 44 dB
    Cartridge Weight: • 10.25 g
    Recommended Load Resistance: • ≥ 47kΩ
    Recommended Load Capacitance: • n/a
